Empowering India’s Electronics Revolution 1000+ Assembly Lines Built 20+ Years of Excellence www.titanteal.com connect.teal@titan.co.in MAKE IN INDIA
AUTOMATION SOLUTIONS THAT DRIVE PROGRESS. End-to-end automation solutions that power industries and shape the future.
01 About Us
ABOUT US Titan Engineering and Automation Limited (TEAL), a wholly owned subsidiary of Titan Company Limited, a Tata enterprise, is a deep-tech engineering organization focused on designing and building next-generation automation, testing, and manufacturing equipment for India’s rapidly growing sectors such as automotive, electronics, and semiconductors. Headquartered in Hosur, Tamil Nadu, TEAL has evolved into a global provider of high-end automation solutions and precision manufacturing.The company operates through two major divisions Automation Solutions and Manufacturing Services delivering turnkey assembly and testing systems for the automotive, energy, electronics, medical devices, and consumer products sectors, as well as high-precision components for industries such as aerospace, defence, and semiconductor equipment. 5000+ Engineers 150+ Clients 850+ Projects 21+ Countries Exported Sq.ft Shopfloor Space 900K+ 250+ CNC Machines
SEGMENTS 01 About Us Automotive Electronics Electrical Semiconductor New Energy Aerospace & Defence Medical Devices Consumer Packaged Goods
Our Journey so Far 1990 In-house machine building with 300+ precision watch assembly lines WATCH ASSEMBLY 2004 Strategic Precision Engineering Division (PED) serving the Transport segment AUTOMOTIVE 2010 MEDICAL Devices 2007 2009 ELECTRICAL & ENERGY First export to USA EXPORT
EMS SEGMENT 2023 2021 USA OFFICE TEAL USA Incorporated 02 Our Journey 2019 2014 CONSUMER PRODUCT GOODS TITAN ENGINEERING & AUTOMATION LIMITED A Wholly owned Subsidiary of Titan company Ltd Branch Office at Germany GERMANY OFFICE 2017
Why TEAL ? Precision, Reliability & Scale Faster time to market Experience of over 1000 installed Machines Local Support Trusted TATA legacy Our Specialization Prototype to Product - 4 weeks Bring up Support Until Mass Production Conceptualize line Sustained On-Site Support 24*7 Localisation of Hardware and Software Execution
Our Offerings End-to-End Assembly Lines Mobile phones, consumer electronics, PCB assemblies Onsite service support Expert onsite support for installation, maintenance, and rapid troubleshooting 03 oUR OFFERINGS Industry 4.0 & Smart Factory Integration 2D & 3D Vision Integration, AOI, IIoT, Traceability Analytics etc Custom Robotics & Precision Automation Tailored to high-volume production needs High-Speed Scalable & Testing Systems Future-ready EMS testing solutions: Electrical, LVDT, UTM, EOL & Reliability. Retrofit to 100% Local Hardware Future-ready retrofits with regionally sourced parts.
INTEGRATED DISPENSING SYSTEM High-Precision Fluid Dispensing With Closed-Loop Process Control DISPENSING TECHNOLOGY Valve Types Motion XY Linear Motor · Z Ball Screw Pneumatic Jet Screw Auger Piezo Jet Needle / Diaphragm 1200 mm/s — no accuracy loss Max Speed Repeatability XY ±0.005 mm Z ±0.01 mm Work Envelope 370 × 450 mm Payload 10 kg Max Segments Semiconductor Consumer Electronics Power Electronics Automotive
Key Features Closed-loop bead width & flow rate correction Micron-level repeatability — ±0.005 mm at production speed Multi-valve platform: jet, auger, spray & needle 04 DISPENSING Visual teach, drag-and-drop programming Applications TIM, underfill & die encapsulation Solder paste, flux & conformal coating Sealant, hot melt & structural bonding 2K epoxy, UV adhesive & conductive dispensing
XR Manufacturing Initiatives - Comprehensive Use Case Overview Immersive Workforce Enablement via AR‑Guided machine assembly Augmented Reality–driven, step‑by‑step digital assembly guidance powered by spatial anchoring and contextual overlays on physical machines. Leverages 3D CAD models and rule‑based workflows to standardize full machine assembly, accelerate skill ramp‑up and reduce human error. Model‑Based AR Work Instructions (3D SOPs) Model‑based enterprise SOPs delivered through AR using lightweight 3D assets derived from PLM/CAD systems. Operators execute structured, sequence‑controlled workflows with real‑time visual validation, improving first‑time‑right execution and process compliance.
MR - Machine Assembly Training Fully immersive MR training modules built on interactive digital twins of sub‑assemblies and deployed on Meta Quest headsets. Enables controller‑based manipulation, spatial learning, and repeatable simulation of assembly tasks without reliance on physical equipment or shop‑floor availability. 05 XR Experience 3D SOPs AR‑Guided machine 3D CAD models Accelerate skill ramp‑up, and reduce human error MR - Machine PLM/CAD systems Sequence‑contr olled workflowsController‑ba sed manipulation
ADVANCED AOI MACHINE VISION EQUIPMENT Intelligent inspection. Engineered for precision manufacturing. TEAL delivers production-ready Automated Optical Inspection equipment by combining vision engineering, algorithms, automation and machine integration for complex quality inspection applications. INSPECTION TECHNOLOGY STACK 2D Vision Fast, deterministic inspection Deep Learning For variable defects 3D Vision Measure real geometry • Presence / absence • Position & orientation • Dimension, OCR/OCV • Anomaly detection • Classification & detection • Segmentation • Height & coplanarity • Flatness / warpage • Tilt & profile Segments Semiconductor EMS Cell & Battery MedTech Precision Manufacturing
TEAL NetrAI PLATFORM LAYER 2D & 3D Automated Optical Inspection Acquisition Recipe Calibration Algorithm plug-ins Visualization Traceability Hardware Independence Works with your existing gige cameras, no vendor lock-in High Inspection Accuracy Proved 99% inspection accuracy for an international customer Optimized TCO 7% to 10% lower total cost of ownership basis application. Universal PLC Connectivity Seamlessly connects to any industrial plc Closed-Loop Correction Eliminates defects at source with auto-correction Plug & Play Deployment Intuitive, sample-based training, no coding required 06 AOI
PCBA 3D AOI SYSTEM TEAL Inspection Workflow Powered by 2D/3D Laser Profiler The demo scans PCBA surface height data and converts it into quantitative measurements for assembly quality decisions. FROM LASER PROFILE TO QUALITY DECISION PASS / FAIL decision PLC / machine integrationMeasure & inspect3D height mapLaser profile * Inspection focus: component height • tilt • connector seating • pin/header coplanarity • PCB/PCBA warpage • profile deviation
Key Features: MULTI-POINT INSPECTION Measure hundreds of points simultaneously for fast and comprehensive inspection. High-Speed 3D Measurement Capture detailed 3D profiles for precise dimensional inspection. FLEXIBLE INSPECTION TOOLS Built-in tools for dimensional, profile, surface and identification inspection. WIDE MEASUREMENT RANGE Multiple sensor heads support different target sizes and measurement requirements. SPECIFICATION Sensor type 2D/3D Laser Profiler Profile data Up to 3,200 points / profile Scan width Selectable head range: 8–720 mm Height repeatability Down to 0.3 μm depending on head 3D scan trigger Up to 16 kHz controller capability System output 3D height map + measurements + pass/fail Integration Motion, PLC / I/O, recipes, traceability 07 3D VISION Inspection
Dual-Head Gantry CO₂ Laser PCB Marking Machine Gantry-based CO₂ / UV laser marking system for permanent top- and bottom-side PCB identification, with pre-mark fiducial alignment, Z-axis focus and post-mark code. Laser Technology Gantry-Based Marking Architecture Post-Mark Verification Top & Bottom in one platform Z-Axis Focus Pre-Mark fiducial Alignment Width-Adjustable Conveyor Segments Semiconductor Consumer Electronics Power Electronics Automotive PROCESS FLOW PCB Loading Vision Alignment Top-Side Marking Bottom-Side Marking
LASER & MARKING Laser Type Laser Configuration Head Mounting Marking Reach (per head) Minimum Mark Size Maximum Mark Size Laser Power PCB Size Range Pallet Handling Conveyor CO₂ / UV Single / Dual head — top + bottom Gantry-mounted, both sides 550 × 460 mm 2 × 2 mm Up to full marking reach 10-30W 50 × 50 mm to 510 × 460 mm Supported Width-adjustable to product size PCB Transfer Mark Verification PCB Unloading Applications Marking Capability Q R Code Data Matrix Serial Number PCB Id Logo Alphanumeric Target Industries E MS Consumer Electronics Automotive Electronics Industrial Electronics Power Electronics 08 Laser Application
GLOBAL PRESENCE India Chennai Retrofit, Assembly & Testing Hosur Head Quarters Delhi-BD & Service DelhiPune BD, Design & Testing SA Rest of the WORLD Germany TEAL Branch Office USA Incorporated China Design Office OUR electronics & AUTO electronics CUSTOMERS Germany India China SCAN ME LinkedIn
